LD Systems Receiver For The MEI1000G2-B5 In-Ear Monitoring System

LD Systems Receiver for the MEI1000G2-B5 In-Ear Monitoring System
This LD Systems unit is an additional belt pack receiver for the MEI1000G2 wireless in-ear monitoring system. This allows you to expand the number of receivers per transmitter, for performers requiring the same monitor mix. No limit to the amount of receivers.

Expand Your Monitoring Setup
The new LD Systems MEI1000G2BPR B5  is an additional belt pack receiver for the MEI1000G2 wireless in-ear monitoring system. Allowing you to expand the number of receivers per transmitter. Perfect for band member that require the same monitor mix. Receiving the 584 – 607 (B5) frequency band. Switchable mono, stereo, and focus monitoring modes as well as adjustable EQ and limiter functions permit natural sound reproduction for any application, with a frequency response of 60 Hz – 16 kHz, a high S/N ratio, and low THD. The LD MEI 1000 G2 allows you to have as many belt pack receivers as you need for your application (there is no limit). The multi-functional display on the receiver shows all relevant system information. With high quality batteries, it is possible to attain operating times of 12 hours and more.

NOTE: This product is only the belt pack receiver. You would need to supply your own in-ear headphones. See here for further recommendations for in-ear monitor headphones.

Features:

• Additional beltpack receiver for MEI1000G2 in-ear monitoring systems
• 96 channel diversity (8 banks of 12)
• Wireless synchronization of transmitter to receiver
• User-friendly menu operation with more control options
• Illuminated graphic display
• Up to 12 hours operation (batter-dependent)
• 3.5mm audio jack output for use with standard earphones

Specifications:

• Operation frequency: 584 – 607 MHz
• Channels: 2 x 96 (8 groups of 12 channels)
• Transmission: method FM, stereo
• Frequency response:  60Hz – 16kHz
• Signal-to-noise: 80 dB
• THD: < 1 %
• Audio output: 3.5 mm TRS
• Max. audio output level: 100 mW
• Controls: down , Escape , set , up , volume
• Indicators: LC display , low battery , Power
• Operating voltage: 2 x 1.5 V AA
• Operating time: > 12 hrs., battery-dependent
• Dimensions: 65 x 90 x 24 mm
• Weight: 0.1 kg
